950mm Oil Tank Stroke Model HQ360-900 CNC Plate Sheet Heating Bending Machine 4.2x4.5x4.1m Overall Size

About 950mm Oil Tank Stroke Model HQ360-900 CNC Plate Sheet Heating Bending Machine 4.2x4.5x4.1m Overall Size

Product Features

1.  It is equipped with a CNC programmable controller, featuring touchscreen-based information input and status feedback for streamlined operation.

2.  It adopts intelligent ultrasonic frequency induction heating, which enhances production efficiency, lowers production costs, and ensures compliance with factory environmental protection standards.

3.  This multi-functional machine eliminates the need for additional tooling and molds, enabling versatile application.

4.  CNC control technology guarantees the forming angle of workpieces, ensuring consistent product quality while boosting production efficiency.

5.  Equipped with an independent hydraulic system and electrical control system, it offers user-friendly operation, reliable safety performance, and high production efficiency.

6.  For angle steel with a size smaller than L100L10010, cold pressing can be applied when the bending angle is less than 5 degrees.

7.  Processing speed: The average cold pressing cycle takes 10 seconds per operation, while the heating processing cycle takes 120 seconds per operation (subject to actual processing materials).  Workpieces are processed when the heating temperature reaches 800C (i.e., red-hot state), with the temperature adjusted based on actual materials and bending angles.

8.  During the heated processing of workpieces, after parameter setting, press the cycle start button or step on the foot switch to initiate fully automated operations, including heating advancement, heating, heating withdrawal, workpiece pressing, press head lifting, and workpiece removal.

9.  For cold pressing (either standalone or post-heating), parameter setting is required to start cold pressing directly.  The press head does not need to return to the origin, and the lower pressing mold rises to a 100mm gap for convenient workpiece removal, ensuring high work efficiency.

Precision and Productivity Combined

Engineered for demanding industrial environments, the HQ360-900 ensures exceptional bending precision of 0.01 mm and rapid processing speeds up to 6 cycles per minute, depending on material and configuration. Heavy-duty construction paired with a variable-speed servo motor drive results in reliable, repeatable quality for every operation.


Integrated Heating Module for Superior Results

Featuring an advanced sheet heating system, this CNC machine enables uniform temperature distribution across the workpiece. The efficient heating method ensures optimal bending results, especially on high-strength steels, while reducing energy usage and improving overall bending consistency.


Operator-Centric Controls and Full Safety

User-friendly colored HMI touchscreen interface combined with multi-axis CNC controls allows for straightforward programming and operation. Designed with a fully enclosed structure and safety interlocks, it maintains the highest standards of workplace safety, protecting operators at every step.
