Double Or Single Blade Cnc Steel Angle Cutting Punching Machine Line 80m/Min Feeding Speed

Double Or Single Blade Cnc Steel Angle Cutting Punching Machine Line 80m/Min Feeding Speed About

Product Features:

1. The CNC angle iron punching machine is equipped with either two or three punching units, each capable of accommodating three distinct punch sizes. These units are precisely controlled by numerical control (NC), ensuring accurate positioning adjustments for punching operations. The machine is capable of producing both round and oval holes. With its high-speed feeding and punching capabilities, it significantly enhances production efficiency. For 50*50*4mm angle steel, the machine achieves a production output of 9-10 tons within an eight-hour shift.

2. The marking unit of the CNC angle punching machine is housed in a robust and durable enclosure. The marking system is designed with four cassette sets, which can be selected via programming, offering flexibility for adjusting the marking position. Additionally, the machine employs a disc marking technique with 10 rows, automatically selecting characters without the need for manual input, thereby substantially improving marking efficiency.

3. The CNC angle bar cutting machine is equipped with a single-blade shearing unit, renowned for its superior cutting force. Each cut is executed with no material wastage, resulting in a clean and smooth cutting surface. The blade housing features an open-door design, facilitating quick and safe blade replacements.

4. The horizontal material table efficiently transfers the angle bar to the rotating material rack, which is powered by a motor and reducer. This mechanism ensures precise positioning of the angle bar onto the feeding conveyor for further processing.

5. The workpiece is securely held and advanced by a CNC feeding carriage, ensuring accurate alignment and positioning. The feeding carriage is driven by a servo motor and incorporates feedback from a photoelectric encoder, operating within a closed-loop control system for enhanced precision.

6. The CNC angle steel metal punching and marking machine operates through a hydraulic system that powers the punching, marking, and shearing functions. It is equipped with a high-speed hydraulic station that includes an accumulator, and the hydraulic lines feature ferrule-type connections, ensuring leak-proof performance and simplifying replacement and maintenance. The main hydraulic valve blocks are sourced from the reputable Atos brand, ensuring a reliable and high-performance hydraulic system.

7. The hydraulic station's cooling system provides multiple options, including water cooling, air cooling, or oil chilling. This versatility allows customers to select the most suitable cooling method based on their specific operational requirements.

8. The control system consists of an upper computer, PLC, servo motor, external detection switches, and other vital components. The operator simply inputs the processing requirements, and the system automatically generates the corresponding processing program. It is fully compatible with file formats such as DXF, NC, and others produced by CAD software. The upper computers human-machine interface is highly intuitive, featuring a user-friendly display and streamlined operation. It includes capabilities such as graphical visualization of workpieces, extensive data storage, location data tracking, and fault alarm notifications.
