CNC Angle Drilling and Marking Machine Used in Angle Steel Tower Industry

Model

ADM2532

Angle size(mm)

140*140*10250*250*32

Max. length of raw material (m)

14

Marking force(kN)

1000

No. of character group

1

No. of character

18

Character size (mm)

14*10*19

Range of accurate distance(mm)

50220（Stepless）

No. of drill on each side

3(2 groups, 6 in total)

No. of blade on each side

3

Taper of drilling spindle

BT40

Max. drilling diameter (mm)

Î40

Max. Spindle rotation speed(r/min)

6000

Drill cooling unit

MQL 360-2（Dry cooling）

Cooling unit oil storage capacity

2L

Cutting oil

Vegetable oil-based micro cutting oils（2000-25）

fuel consumption

550ml/h

CNC trolley drive type

AC servo motorãrack and pinion driving

Max. feeding speed of angle(m/min)

40

AB-axis alignment movement drive method

Linear Motion Guide;AC servo motor;Ball screw Secondary driving

Max. skateboard travel speed of drilling head(m/min)

10

Drilling head drive type

Linear Motion Guide;AC servo motor;Ball screw Secondary driving

Max. feeding speed of drilling head(m/min)

14

Feeder trolley arm working method

Vertical lifting type

Number of tipping cylinders on discharge side

4

Hydraulic station cooling method

Air cooling

No. of CNC axes

9

Air pressure（MPa）

1

Total power

About 150KW

Machine weight (kg)

About 33 tons

Overall dimensions(m)

33*8.5*2.5
