Send InquiryHeavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120
Price 300000.00 INR/ Unit
MOQ : 1 Unit
Heavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120 Specification
- Product Type
- Heavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120
- General Use
- Industrial
- Material
- Metal
- Automatic
- Yes
- Power Source
- Electric
- Power Consumption
- 15 Kilowatt (kW)
- Dimension (L*W*H)
- 38000 x 7500 x 5000 mm Millimeter (mm)
- Warranty
- Yes
Heavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120 Trade Information
- Minimum Order Quantity
- 1 Unit
- Supply Ability
- 10 Units Per Day
- Delivery Time
- 30 Days
About Heavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120
characteristics:
The production tine for automotive longitudinal beamis an efficient and highprecision automated sheetmetal processing equipment specially designed by our company for punching high-strength longitudinalbeams for automobiles Suitable for punching the longitudinal beams of ultrawide and ultra thick vehiclessuch as mining trucks and special vehicles.
Basic parameters of abdominal flushing:
|
Main machine body type |
Semi closed form |
|
Sheet |
|
|
|
4000-15000 |
|
|
Flat panel 200-750 mm U-beam 200-500 mm |
|
Maximum tensile strength |
8b=510-950 |
|
machine punching force |
1700KN,2000(optional) |
|
|
|
|
Max.punching diameter |
60mm |
|
|
38000x 7500x 4500mm |
|
Overall weight |
About 43 tons |
Productpurpose andcharacteristics:
The production line selects the upper front belly hole as the positioning hole for wing face processing,achiev- ing reliable,efficient,flexible,and fully automatic punching of equal cross-section longitudinal beams,which has a high cost performance ratio.
Automatic measurement and accuracy compensation of the shape error of longitudinal beams;Well config- ured and controlled by Siemens CNC system from Germany to improve reliability;Dual channel control,high processing efficiency;Filter type stamping,the longitudinal beam only moves forward but not backward.
Cutting-Edge Automation for Industrial Metalworking
The FPCP120 production line is designed with state-of-the-art CNC technology, providing seamless automation for longitudinal beam and flat plate punching. Its automatic operation reduces manual intervention, increases safety, and boosts productivity, making it an ideal choice for large-scale manufacturers.
Engineered for Durability & Efficiency
Constructed from high-grade materials, this production line stands up to the demands of continuous, heavy-duty use. Its 15 kW electric power source is optimized for high performance while minimizing energy costs. Engineered in China, it meets global standards for industrial machinery.
FAQs of Heavy-Duty Vehicle Longitudinal Beam Flat Plate CNC Punching Production Line Model FPCP120:
Q: How does the FPCP120 CNC Punching Production Line operate automatically?
A: The FPCP120 uses advanced CNC controls and programmed settings to manage the punching process, allowing materials to be loaded and processed with minimal human intervention. This automation streamlines production, enhances accuracy, and reduces labor requirements.Q: What types of materials can the FPCP120 handle during operation?
A: This production line is designed for punching flat plates made of various metals, supporting a wide range of heavy-duty industrial applications relating to vehicle longitudinal beam manufacturing.Q: Where is the FPCP120 manufactured and available for export?
A: The FPCP120 is manufactured in China and is available globally through various channels, including distributors, exporters, suppliers, and traders, ensuring worldwide accessibility.Q: When should a facility consider using the FPCP120 CNC Punching Line?
A: Facilities seeking to increase punching capacity, improve automation, and enhance the precision of longitudinal beam or flat plate processing should consider integrating the FPCP120 into their operations, especially in high-volume industrial environments.Q: What is the process flow of the FPCP120 in a production environment?
A: Materials are loaded onto the line, where the CNC system guides them through automated positioning and punching routines. The punched plates are then collected for subsequent processes or assembly, ensuring an efficient and repeatable workflow.Q: How does the FPCP120 benefit industrial users?
A: With its reliable automatic operation, significant power efficiency, and precise control, the FPCP120 boosts productivity, lowers labor costs, and delivers consistent results for heavy-duty manufacturing tasks.
