Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine

Send Inquiry

Request To Call Back

Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine

Price 37000 USD ($)/ Unit

Get a Price/Quote

MOQ : 1 Unit

Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine Specification

Product Type
Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine

General Use
Steel plate processing, fabrication, and preparation

Material
Carbon steel, mild steel, stainless steel plates

Type
CNC Plate Punching, Drilling, and Marking Machine

Capacity
Max. plate thickness 40 mm, max. width 1500 mm

Weight (kg)
Approx. 5000 kg

Computerized
Yes

Automatic
Fully automatic operation

PLC Control
Available, industrial grade

Bar Feeder
Integrated automatic bar feeder

Power Source
Electric

Power Consumption
Approx. 15-18 kW

Rigidity
High rigidity steel construction

Voltage
380V/415V, 50/60 Hz, 3 Phase

Motor
Servo motor driven

Table Size
2000 1600 mm

Spindle Speed
301200 rpm (variable)

Axial Choice
3-axis CNC controlled

Dimension (L*W*H)
Approx. 4200 2200 2400 mm

Feature
Punching, drilling and marking integration with automatic material feed

Color
Industrial grey/blue

Warranty
Yes

Cooling System
Automatic water-cooling for drilling head

Marking Type
Programmable CNC marking head

Workpiece Loading
Side-loading with motorized rollers

Lubrication System
Automatic central lubrication

Punching Force
1200 kN

Safety Features
Emergency stop, light curtain, safety guard interlocks

Max Drilling Diameter
50 mm

Clamping Type
Automatic hydraulic plate clamps

Operating Temperature
5C 45C

Noise Level
<80 dB

Positioning Accuracy
0.1 mm

Hydraulic System
High-pressure integrated hydraulic system

CNC Controller Brand
Siemens/Fanuc (optional)

Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Day

Delivery Time
30 Days

Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine About

Access the unrivaled precision of the Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine-a famed solution for steel fabrication. With a max drilling diameter of 50 mm and powerful 1200 kN punching force, this fully automatic machine offers gorgeous programmable marking. Featuring Siemens/Fanuc controllers and industrial-grade safety, it seamlessly integrates punching, drilling, and marking with automatic material feed. Purchase now to secure this hot deal, engineered for superior reliability in carbon, mild, and stainless steel plates up to 40 mm thick. A true asset for distributors, exporters, and manufacturers worldwide.

Optimized Usage and Material Versatility

This machine is designed for industrial-grade steel plate processing, fabrication, and preparation. Its robust construction and programmable CNC marking head allow for precision in a broad range of applications-be it punching, drilling, or marking on carbon steel, mild steel, or stainless steel plates. The automatic clamping and side-loading system make it ideal for high-volume plant operations where speed, accuracy, and consistency are paramount to production lines.

Logistics, Market Reach & Supply Capacity

Our hot deal on the Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine ensures swift order processing and reliable shipment of goods. Exported to major markets across Asia, Europe, Africa, and the Middle East, our distribution network meets broad industrial demands. With significant supply ability, customers can estimate shipment timelines and access consistent support, reinforcing trust from order placement to delivery across both domestic and export markets.

Specifications:

Model		BNC100		BNCZ100
Max size of work piece LiW(mm)		1500i800
Max. punchingdiameter (mm)		i26
Max. drillingdiameter (mm)		/	i50
Plate thickness (mm)	Punching	5i25(Q235)
	Drilling	40
Punching force(kN)		1000
Marking force(kN)		800
Min. distance between hole and plate edge(mm)	Punching	25
	Drilling	Depends on hole diameter
Character size(mm)		14i10i19
No.of character		12
Die-stations		3	4
Feeding speed of drilling(mm/min)		/	25280
Stroke of drilling spindle(mm)		/	180
Rotation speed of drilling spindle(r/min)		/	120560
Precision		Accordance with GB2694
Programming mode		Input by keyboard, RS232 interfaceand USB interface
Overall dimensions LiWiH(mm)		3200i3000i1900		3200i3000i2600
Machine weight (kg)		About 5400		About 5800

FAQ's of Automatic CNC Steel Plate Hole Punching Drilling and Marking Machine:

Q: How does the machine handle steel plate loading and positioning?

A: The machine features side-loading with motorized rollers and automatic hydraulic plate clamps, ensuring rapid and precise positioning for all operations.

Q: What types of materials does this machine process?

A: It is engineered for use with carbon steel, mild steel, and stainless steel plates, handling thicknesses up to 40 mm and widths up to 1500 mm.

Q: What is the main benefit of its programmable CNC marking head?

A: The programmable CNC marking head allows for automated, precise, and customizable marking, improving workflow efficiency and minimizing manual intervention.

Q: Where can this machine be shipped, and what is the order process like?

A: We ship globally-including Asia, Europe, Africa, and the Middle East. Order processing is streamlined to provide timely estimates and status updates until goods are shipped.

Q: What safety features are included in the design?

A: The machine is equipped with emergency stop buttons, light curtains, and safety guard interlocks to ensure operator safety during operation.

Q: How does the integrated cooling and lubrication system benefit usage?

A: Automatic water-cooling for the drilling head and central lubrication reduce tool wear, maintain accuracy, and extend machine life for continuous operation.
