3 Axes Automatic Loading and Unloading Device Automobile Truck Beam Plate CNC Punching Machine

About 3 Axes Automatic Loading and Unloading Device Automobile Truck Beam Plate CNC Punching Machine

1. Application:

This machine is a special equipment for punching holes in flat longitudinal beams in the automotive industry.

2. Structural composition:

This machine is mainly composed of automatic loading and unloading devices, centering devices for automatic compensation of variable-section plates, feeding devices, punching units, automatic waste output devices, and hydraulic, electrical, and pneumatic systems.

3. Product features:

1. The control system adopts SIEMENS 828D CNC system, servo motor feeding, high working efficiency, stable workpiece precision.

2. The servo center centering device is installed on the feeding support roller, which can meet the processing of variable cross-section plates with a drop of 0-200mm.

3. 25 molds with different diameters can be installed, and the installation is quick and convenient.

4. The uploading, punching and downloading of the plate are completed automatically, thereby reducing the work intensity.

5. Automatic output and collection of waste.

6. The automatic programming software can directly call the graphics of AUTOCAD or the graphics in .DXF format generated by other CAD software, and complete the automatic generation of machine tool processing programs through a friendly human-machine interface, saving time and without errors.

Advanced Automation for CNC Punching

This device automates the loading and unloading of automobile truck beams and plates, streamlining workflows in CNC punching processes. By integrating seamlessly with CNC machines, it reduces manual labor and minimizes downtime, allowing for continuous, high-precision manufacturing.


Energy-Efficient, High-Speed Performance

Engineered for efficiency, the machine offers high throughput while maintaining low energy consumption. Its electric-driven operation ensures rapid movement and accurate positioning, delivering optimal productivity with minimal overhead costs.


Reliable Warranty and Global Supply

Customers are assured with a comprehensive warranty, covering quality and performance. As a product designed, manufactured, and supplied by an established Chinese exporter, it is supported by global distribution channels for easy acquisition and dependable after-sales service.
